Initial Activation
Wired Mode
Plug in the USB-C cable to activate the keyboard and enter Wired Mode.
2.4GHz Mode
Long press FN + ESC for 3 seconds to power on and enter 2.4GHz Pairing Mode.
Bluetooth Mode
Short press FN + 1, then long press both for 5 seconds.
The indicator will flash blue rapidly, entering Bluetooth pairing mode.
On your device, select [IQUNIX FOX98 BT1].
The indicator turns off once pairing is successful.
To pair with more Bluetooth devices:
Repeat the same steps using FN + 2 or FN + 3.
Switch between devices using FN + 1 / 2 / 3.
2.4GHz Mode
Short press FN + 4.
Insert the 2.4GHz receiver into your device.
The indicator light will flash pink rapidly while pairing.
The indicator turns off automatically once connected.
Win / Mac Layout Switch
FN + Tab Toggle between Windows/macOS layout
FN + Win Lock or unlock the Windows key
FN + Space Restore default settings
Backlight Settings
FN + Z Toggle backlight On/Off
FN + X Decrease backlight brightness
FN + C Increase backlight brightness
FN + V Slow down lighting effect speed
FN + N Speed up lighting effect speed
FN + Enter Switch backlight effect
FN + Shift Change backlight color
Battery & Charging
Check Battery: Press FN + B
The indicator light will flash to represent the battery level:
1 Flash 10%
2 Flashes 20%
3 Flashes 30%
... ...
10 Flashes 100%
Charging Status:
Yellow light flashes 4x = Charging
Green light flashes 4x = Fully charged
Power On / Off
Long press FN + ESC for 5 seconds to power on/off
⚠️ Note: USB-C cable must be unplugged to power off
